11254421 - FLOW REGULATOR HFCV10-HRT-P-E-13.2-00 - DANFOSS

Description: HFCV10-HRT-P-E-13.2-00

Flow Control, Fully Adjustable, Pressure Compensated, Restrictive Type with Reverse Free Flow 350 bar [S000 psi]• 45 I/min [12 US gpm]

This is a fully adjustable, restrictive type, pressure compensated flow control valve from port 1 to 2 with a reverse free flow check from port 2 to 1. The flow from port 2 will remain constant regardless of the pressure difference across the valve. Flow enters at port 1 and passes across an adjustable orifice in the spool, which creates a pressure drop. This causes the spool to move back against the spring, which then restricts the outlet flow. Flow from port 2 to 1 passes freely across an integral check valve.
