102799 - POPPET VALVE 3-WAY - AEXd32060b-G48/L15-K9M187 - WANDFLUH

Solenoid operated poppet valve

Flange construction

  • 2/2-, 3/2- and 3/4-way
  • normally open and normally closed
  • Qmax = 40 l/min
  • pmax = 350 bar

Price available only for registered users

If you need help Contact Us!

Description:

Direct operated 2/2-, 3/2 and 3/4-way solenoid poppet valve in flange construction. By means of the pressure tight switching solenoid, the poppet valve spool is opened or closed acting against the spring. Due to the poppet spool construction with pressure compensation on both sides, the flow through the valve is possible in both directions. The metallically sealing seat closes the valve virtually leak free. The pressure tight encapsulated Ex-protection solenoid coil prevents an explosion on the inside penetrating to the outside as well as an ignitable surface temperature

Application

These valves are suitable for applications in explosion-hazard areas, open cast and also in mines. Poppet valves are used where tight closing functions of the valve are essential like leakage-free load holding, clamping or gripping
