171184419 - COIL - M16-220RA-22W-DN - DANFOSS

171184419 - COIL - M16-220RA-22W-DN

Price available only for registered users

If you need help Contact Us!

  • Duty cycle: 100% at 115% of rated voltage, at 40 °C [104 °F]

  • Magnet wire insulation class: 200 °C

  • Ambient temperature range: -20 to 40 °C [-4 to 104 °F]

  • Environmental protection ratings:

    • IP69K: DE

    • IP67: AJ, AS, and M3 terminals

    • IP65: FL and DN

  • Input voltage range: 85% to 115% of rated voltage

  • Temperature rise at 115% of rated voltage: 130 °C [266 °F] above ambient

  • AC coils: Require an external rectifier

  • Weight: 0.24 kg [0.53 lb]

171184419
Danfoss
