11126197 - 2-WAY - SVP10-NC-M-00-00-B-00 - DANFOSS

Solenoid Valve, 2-Way, Poppet Type, Normally Closed, Pilot Operated
230 bar [3300 psi] • 80 l/min [21 US gpm]

OPERATION AND DESCRIPTION
This is a 2-way, 2-position, pilot-operated, poppet-type solenoid valve, normally closed in its de-energized state.
When de-energized, flow is allowed from port 1 to port 2, while flow in the opposite direction is blocked.
When energized, flow is allowed from port 2 to port 1, while reverse flow is restricted.

Some models are available with an optional filter at port 2.
Thanks to the low leakage design of the poppet construction, these valves are ideal for applications requiring load holding or for safely diverting excess oil to tank.
